E-100DV
The E-100DV is a dual-spindle bridge mill design for machining longer parts. It is equivalent to two machines in a single footprint. Its 2-head construction allows independent offsets and synchronized operations of the Z axis and W axis, resulting in the ability to produce two products in a single operation as well as a short loading/unloading time.
30Taper |
7HP Spindle |
24kRPM |
Product Overview
The E-100DV is a dual-spindle bridge mill design for machining longer parts. It is equivalent to two machines in a single footprint. Its 2-head construction allows independent offsets and synchronized operations of the Z axis and W axis, resulting in the ability to produce two products in a single operation as well as a short loading/unloading time.
![pm-last-longer](https://139128.fs1.hubspotusercontent-na1.net/hub/139128/hubfs/.nomurads/NOMURADS%20PARTS/NOMURADS%20MILLING%20PARTS/pm-last-longer.png?width=300&name=pm-last-longer.png)
Nomura DS Machines for Every Industry
CNC machines are used in nearly every application. Discover how Nomura DS machining can enhance your production and boost efficiency in your industry.
Resources |
Support |
Get the knowledge you need to run your operation more smoothly and profitably. Access industry case studies, manuals and more. |
Keep your machine up and running with unmatched technical service and support. |
Specifications
General Info
Floor Space
118.11 x 124.41 in
Table Size
55.12 x 27.56 in
Controller
Mitsubishi M80
Tool Stations
24 x 2
Spindle
Speed
24,000 RPM plus optional RPM (15,000)
Power
7 HP
Taper
30 - BBT30 with face contact
Travel
Travel (X, Y, Z)
25.19(X, U) x 39.37 x 13.78(Z, W)
Rapid Traverse
1889.7 ipm
